Transformer Inrush Current: 5 Proven Fixes for False Trips

A healthy transformer can draw a surge larger than a fault for a few cycles, and protection must know the difference.

Core Saturation Residual Flux 2nd Harmonic Point on Wave

When a transformer is switched on, its core can be driven deep into saturation. The result is a short, lopsided surge of magnetising current that may trip breakers or relays that are not set correctly.

Hello everyone, today we are going to learn what causes transformer inrush current, why it can look like a fault to protection, and which practical methods keep false trips away.
transformer inrush current

What Is Transformer Inrush Current?

Transformer inrush current is the large magnetising current drawn in the first cycles after a transformer is energised. Its peak can reach 8 to 12 times rated current, far above the normal no load current of a few percent.

Eaton explains that the surge is needed to establish flux in the core and decays within a few cycles. The decay rate depends on winding resistance and inductance, so large units can take several seconds to settle.

Typical magnetising inrush waveform with large offset first peaks that decay
Image credit: Eaton

The waveform is very distorted and flows mostly in one polarity. That shape is the key to telling it apart from a real fault.

Inrush happens on the primary only, since the secondary is open or lightly loaded during switching. The same physics also affects current transformers when they saturate.

Why the Core Saturates

Switch ClosesOften near voltage zero
Flux OffsetFlux must start from residual value
Double FluxPeak flux can reach 2Φm plus Φr
SaturationCore permeability collapses
Current SurgeOnly air core inductance limits current

In steady state, flux lags voltage by 90 degrees and peaks at the voltage zero crossing. If the switch closes at that zero, flux starts from its residual value and swings to about twice the normal peak.

Modern cores run near 1.6 to 1.7 tesla, so doubling flux pushes them well past saturation. Eaton notes that the worst case needs maximum residual flux and the worst switching moment together, so it is rare.

Transformer Inrush Current Formulas

Peak flux ≈ 2 × Φm + Φr
Rated current I = kVA ÷ (√3 × kV)
Peak inrush ≈ Multiple × √2 × I

Worked example, 1000 kVA, 0.415 kV secondary energised from LV side:
I = 1000 ÷ (1.732 × 0.415) = 1391 A
Multiple = 10
Peak inrush ≈ 10 × 1.414 × 1391 ≈ 19.7 kA for the first cycle

Manufacturers usually quote the multiple as a peak value relative to the rated RMS current. Use their data where possible, because core design changes the result.

Rated current comes from the nameplate, as shown in transformer kVA rating. Always check which side is switched, since the LV side draws a larger multiple.

Inrush vs Fault Current

FeatureInrushInternal Fault
WaveformOffset, peaky, one polarityNear sinusoidal
2nd harmonicHigh, often above 15 percentLow
DurationCycles to seconds, decayingUntil cleared
Differential currentAppears on one side onlyReal imbalance
Correct responseRestrainTrip fast

Differential relays block tripping when the 2nd harmonic ratio exceeds a set level, commonly 15 to 20 percent. Our protective relays guide covers these functions.

Harmonic content is explained in more depth in power harmonics. Modern relays also use waveform shape and dead angle detection.

5 Proven Fixes for False Trips

1
Correct Breaker Setting
Set instantaneous pickup above the inrush peak for its duration.
2
Harmonic Restraint
Enable 2nd harmonic blocking on differential relays.
3
Point on Wave Switching
Close each pole at the best voltage angle for the residual flux.
4
Pre Insertion Resistors
Limit current for the first cycles, then bypass.
5
Staggered Energising
Switch transformers one at a time to avoid sympathetic inrush.

Breaker curves must pass above the inrush point, a check shown in time current coordination. For smaller units, see MCCB rating selection.

Sympathetic inrush occurs when an already energised transformer draws extra current as a neighbour is switched in. It lasts longer and can confuse protection on both units, especially where two transformers share one busbar.

Effects on the Network

Voltage Dips
Large inrush lowers bus voltage for a moment.
Nuisance Trips
Instantaneous elements may operate.
Winding Stress
Mechanical forces on the coils.
Harmonic Resonance
Possible overvoltage with capacitor banks.
Relay Blocking
Harmonic restraint may delay real fault trips.
Generator Loading
Small gensets struggle to energise big transformers.

The voltage dip can reset sensitive loads, as explained in voltage sag and flicker. Energise large transformers before connecting sensitive equipment.

Peak Inrush Calculator

Rated and Peak Inrush Current
Result
Rated 1391 A, peak inrush 19.7 kA

Use the result to confirm breaker instantaneous settings, CT ratings and genset capacity before commissioning day. Actual inrush is usually lower because the worst switching angle is rare.

Good Practice
  • Get inrush data from the maker.
  • Enable harmonic restraint.
  • Coordinate breaker curves.
  • Energise one unit at a time.
Common Mistakes
  • Instantaneous pickup set too low.
  • Ignoring residual flux after tests.
  • Switching all feeders together.
  • Undersized generator for energising.

Transformer Inrush Technical PDF

PDF
Transformer Inrush
IDC technical reference on energisation, recovery and sympathetic inrush

Inrush Theory Video

Transformer Inrush Current FAQ

What is transformer inrush current?
A large magnetising surge drawn when a transformer is first energised.
How large can it be?
Typically 8 to 12 times rated current at its first peak.
How long does it last?
From a few cycles to several seconds for large units.
Why is it worst at voltage zero?
Flux starts from residual and swings to about twice normal peak.
How do relays avoid tripping?
By detecting high 2nd harmonic content.
What is sympathetic inrush?
Extra current drawn by an energised unit when a neighbour switches in.
How can it be reduced?
Point on wave switching, pre insertion resistors and correct settings.

Related Articles

External References

What We Learn Today

  • Transformer inrush current peaks when the core saturates after switching near voltage zero.
  • Inrush is offset, peaky and rich in 2nd harmonic.
  • Correct settings and controlled switching stop false trips.
I hope you like above blog. There is no cost associated in sharing the article in your social media. Thanks for reading!! Happy Learning!!
