ToggleA control valve reading zero percent open on the DCS screen isn't proof that flow has actually stopped. Control valve passing is one of the most misdiagnosed problems in a process plant, and replacing a healthy valve rarely fixes it.
Control valve passing means process fluid keeps moving through a valve that the control system believes is fully shut, and it's almost always a symptom of a different underlying problem rather than valve failure itself.
Steam, water, gas, chemicals or slurry, it doesn't matter what's flowing. When a valve keeps passing after the controller commands zero percent, plants see unexpected temperature spikes, rising downstream pressure, or a level that never stops climbing. Many engineers assume the control valve itself has failed and order a replacement straight away.

In practice, the valve is usually just showing the symptom of a different disease. The actuator, positioner, instrument air supply, valve trim, process conditions, or even the original valve sizing can all be the actual root cause. Finding that root cause first, before swapping hardware, is what separates a five minute fix from a repeat failure two weeks later.
What Control Valve Passing Actually Means
A control valve moves a plug, ball, disc, or gate against a sealing surface to throttle or stop flow. Once fully closed, flow should drop to whatever leakage rate the manufacturer allows, not to true zero. Engineers use the word "passing" specifically when flow continues well beyond that allowed limit.
Internal Leakage
Fluid flows through the valve seat despite the valve reading fully closed. This is what most engineers mean by "passing," and it's usually caused by worn trim or debris trapped at the seat.
Seat Leakage
Leakage specifically across the internal sealing surfaces. Every valve has an allowable seat leakage limit tied to its shutoff class, so a small amount is normal, not a fault.
Body Leakage
Fluid escapes through the valve body itself, caused by casting defects, cracks, or a failed body gasket. This leaks outward, not through the closed flow path.
External Leakage
Leakage around packing glands, bonnet joints, flanges, or instrument fittings. Serious, but distinct from internal valve passing since it doesn't involve flow through the closed valve.
No standard control valve is truly leak free unless it's specifically built for bubble tight shutoff. Compare the actual measured leakage against the specified shutoff class before concluding the valve has failed.
How a Control Valve Should Close Under Normal Conditions
Knowing the normal closing sequence makes it much easier to spot exactly where things go wrong on a passing valve.
The last few millimeters of stem travel matter more than any other part of the stroke. Even slight damage to the plug, seat ring, or stem alignment at this final stage can prevent proper sealing and let process flow continue.
If the closing force is too low, leakage can continue even after the position indicator reads zero percent. A position reading of "closed" is not the same thing as a valve that has actually sealed.
Common Symptoms of a Passing Control Valve
Recognizing these field symptoms early helps engineers catch control valve passing before it turns into a major production loss. Control valve passing rarely announces itself directly, it usually shows up first as a process trend that just won't settle. Check off anything you're currently seeing on your process.
14 Major Causes of Control Valve Passing
Here are the 14 root causes that actually explain most control valve passing problems in the field, in roughly the order engineers should check them.
Damaged Valve Seat
The seat is the main sealing surface, and continuous service wears, dissolves, or corrodes it over time. High velocity steam grooves the seat through wire drawing, while abrasive slurry particles erode it through repeated impact.
Damaged Valve Plug
Scratches, corrosion, impact damage, or a bent stem stop the plug from making even contact with the seat. Under high differential pressure, even a minor surface flaw on the plug can cause significant leakage.
Foreign Material Between Seat and Plug
Rust flakes, welding slag, scale, sand, or packing debris often get caught between the plug and seat during closure. The plug never fully seats, and a leak channel forms around the trapped debris.
Incorrect Actuator Adjustment
Wrong travel limits, incorrect mechanical stop settings, or insufficient actuator thrust mean the position indicator reads zero percent while the plug is still slightly above the seat.
Insufficient Instrument Air Supply
Low air pressure reduces actuator thrust and stops the valve from seating correctly. Check for tubing leaks, a clogged filter, or a failing regulator before assuming the valve itself is defective.
Positioner Problems
A miscalibrated positioner can stop the actuator short of fully closing the valve. Worn linkages, loose feedback arms, pneumatic leaks, and wrong digital settings all contribute to imprecise positioning.
Valve Sizing Problems
An oversized valve normally operates close to the closed position, where a tiny stem movement causes a huge flow change. This low valve authority makes tight shutoff genuinely difficult by design.
High Differential Pressure
A larger pressure differential across a closed valve pushes harder against the plug and seat. If the actuator wasn't sized for that force, it simply can't produce enough seating force for tight shutoff.
Cavitation and Flashing Damage
Near the fluid's vapor pressure, liquid service can cavitate or flash. Collapsing vapor bubbles pit the internal surfaces, and this erosion slowly destroys the seat and plug's ability to seal.
Trim Erosion
High velocity fluid carrying abrasive particles wears down trim components continuously. This is especially common in power plants, mining, and slurry handling, where sealing surfaces degrade until shutoff performance drops.
Packing Problems
Over-tightened packing increases stem friction to the point where the stem can't reach its final seating position smoothly, even though the packing itself is doing its sealing job correctly.
Stem Misalignment
Bent stems, worn stem guides, excess pipe tension, or a poor installation can misalign the plug and seat. Even minor misalignment creates uneven seating and opens up leak paths.
Actuator Mechanical Failure
A broken spring, ruptured diaphragm, damaged piston, worn seal, or sticking mechanical part inside the actuator can all reduce closing force enough that the actuator never completes its full stroke.
Wrong Valve Type Selected
Choosing a throttling globe valve where bubble tight isolation is actually required, or a butterfly valve for a severe differential pressure service, is a design mismatch that shows up later as chronic passing.
Control Valve Shutoff Performance by Valve Type
Selecting the right valve type for the application matters just as much as maintaining the trim correctly.
| Valve Type | Typical Shutoff Performance | Common Applications |
|---|---|---|
| Globe Valve | Excellent control, good shutoff | Steam, flow, pressure, and temperature control |
| Ball Valve | Excellent isolation, bubble tight shutoff | On/off applications |
| Butterfly Valve | Moderate, depends on seat design | Cooling water, HVAC, utilities |
| Plug Valve | Good isolation, simple construction | Chemical and utility services |
| Gate Valve | Isolation only, not for throttling | Pipeline isolation |
How to Troubleshoot a Passing Control Valve
Troubleshooting control valve passing well means resisting the urge to disassemble the valve first. A systematic approach prevents unnecessary replacement, and most control valve passing cases resolve at step 5 or earlier. Work through these steps in order rather than jumping straight to disassembly.
Field experience consistently shows that combining process data with a physical inspection identifies the real root cause far faster than replacing components one at a time.
Field Diagnostic Techniques for Detecting Control Valve Passing
Modern plants combine several diagnostic methods to confirm internal valve leakage before opening anything up.
Pressure Gauges
Reveal unexpected pressure changes across a valve that should be closed.
Temperature Readings
Detect leaking steam valves through unwanted heat transfer downstream.
Portable Flow Meters
Verify whether fluid is still flowing after the valve is commanded shut.
Ultrasonic Leak Detectors
Listen for the high-frequency sound produced by an internal leak.
Thermal Cameras
Spot hot regions instantly, useful for finding a faulty steam valve fast.
Valve Signature Analysis
Evaluates friction, seating force, and travel characteristics together.
Digital Valve Diagnostics
Flags travel deviation, hysteresis, and excessive friction automatically.
Partial Stroke Testing
Confirms the actuator moves freely without ever stopping the plant.
Online Condition Monitoring
Continuous valve health tracking that supports predictive maintenance.
Control Valve Leakage Classes Explained (ANSI/FCI 70-2)
Every control valve gets tested and rated against a leakage class, and comparing measured leakage to the correct class is the fastest way to know if a valve has genuinely failed.
| Leakage Class | Allowable Leakage | Typical Valve Type | Common Industries |
|---|---|---|---|
| Class II | Small allowable leakage | Globe valve | Chemical plants |
| Class III | Lower than Class II | Globe valve | Oil and gas |
| Class IV | Common industrial shutoff, metal-to-metal seating | Globe valve | Refineries |
| Class V | 0.0005 mL per minute, per psi differential pressure, per inch of port diameter | Globe valve with lapped metal seat | Power plants, high pressure steam letdown |
| Class VI | Bubble tight: 2 bubbles/min (1"), 3 (2"), 6 (3"), 11 (4"), 27 (6"), 45 (8") of air at up to 50 psig | Soft-seated valves (PTFE or elastomer) | Pharmaceutical, food, specialty chemical |
Higher leakage classes need tighter manufacturing tolerances and better sealing surfaces. Always verify the specified leakage class on the datasheet before concluding a valve is defective, since some leakage may still fully comply with its design standard.
Live Class V Leakage Rate Calculator
Class V shutoff is defined by a strict formula rather than a percentage of flow capacity: 0.0005 mL of water per minute, per inch of port diameter, per psi of differential pressure. Enter your valve's port diameter and differential pressure to check the allowable leakage.
Real Industrial Example of a Passing Control Valve
Process Problem
A refinery reactor showed inconsistent temperature control because a steam control valve kept reading zero percent open, yet reactor temperature kept climbing during low output hours.
Root Cause Investigation
The operations team first suspected poor controller tuning and retuned the loop several times, but the temperature problem persisted. Technicians then confirmed positioner calibration, actuator travel, and instrument air pressure were all within specification.
Inspection Findings
During a scheduled outage the valve was pulled for inspection. Engineers found extensive cavitation damage on the plug and seat, with microscopic grooves that let steam pass even at full closed travel.
Corrective Action and Results
The damaged trim was replaced with a cavitation-resistant design suited to the actual service conditions. A follow-up seat leakage test confirmed the valve met its required shutoff class, reactor temperature stabilized, and steam consumption dropped back to normal. Retuning the controller alone could never have solved a mechanical trim failure.
Do's and Don'ts When Diagnosing Control Valve Passing
✔ Do
- Check the process trend before touching the valve itself
- Compare measured leakage against the actual specified shutoff class
- Verify instrument air pressure and positioner calibration first
- Inspect trim for cavitation, erosion, or debris during any planned outage
✘ Don't
- Assume the valve has failed just because it's passing
- Replace the valve before confirming actuator and positioner health
- Ignore high differential pressure conditions the valve wasn't designed for
- Over-tighten packing to "fix" a leak without checking stem friction
Reference Whitepapers on Valve Leakage and Cavitation
Key Takeaways on Control Valve Passing
When a control valve keeps passing fluid after it's fully closed, it's frequently a symptom rather than the actual root cause. Damaged seats and worn trim explain a lot of internal leakage, but the actuator, positioner, instrument air supply, valve sizing, and process conditions can all cause the exact same symptom.
Effective troubleshooting starts with process data, moves through position and actuator verification, and only reaches physical inspection once the simpler checks are ruled out. Choosing the right valve type and leakage class during design prevents most of this trouble from ever showing up in the field.
FAQs on Control Valve Passing
