Instrumentation engineers must have a deep understanding of how various sensors and transducers work, their applications, and how to interpret and condition their signals.
I have created list of 49 advanced objective questions with answers covering working principles, industrial applications, signal conditioning, calibration, and smart sensor technologies.
In this “Sensors and Transducers” series each question is followed by four options (a–d) and the correct answer is also indicated.
Working Principles of Sensors and Transducers
Q) In a Linear Variable Differential Transformer (LVDT), the primary coil is typically energized by:
a. An alternating current (AC) excitation
b. A direct current (DC) supply
c. A battery with a resistor network
d. A permanent magnet coupling
Correct Answer: a
Q) The output voltage of an LVDT is generally:
a. Non-linearly related to core displacement
b. Linearly proportional to the core’s displacement over a certain range
c. A digital pulse train proportional to velocity
d. Zero regardless of core movement (null at all positions)
Correct Answer: b
Q) One key advantage of an LVDT displacement transducer is its:
a. Frictionless operation (no sliding contacts), giving virtually infinite resolution and excellent repeatability
b. Ability to operate without any power source
c. Complete immunity to temperature changes
d. Built-in digital communication interface
Correct Answer: a
Q) A thermocouple measures temperature based on which physical effect?
a. Peltier effect
b. Thomson effect
c. Joule heating
d. Seebeck effect (voltage generated at a junction of dissimilar metals with temperature difference)
Correct Answer: d
Q) Which statement correctly compares platinum RTDs and NTC thermistors for temperature sensing?
a. RTDs (e.g. Pt100) have a near-linear positive temperature coefficient and high stability over wide ranges, whereas thermistors offer higher sensitivity but are highly nonlinear over narrower ranges
b. RTDs are generally less accurate and less stable than thermistors
c. Thermistors typically have better linearity than RTDs across the full range
d. RTDs have a negative temperature coefficient while thermistors have a positive coefficient
Correct Answer: a
Q) The operating principle of a bonded metal foil strain gauge is to measure:
a. Pressure-induced voltage generation
b. Temperature-induced EMF difference
c. Magnetic field changes around a conductor
d. Mechanical deformation (strain) by the change in electrical resistance of the gauge
Correct Answer: d
Q) Piezoelectric accelerometers are unsuitable for measuring:
a. High-frequency vibrations
b. Shock or impact accelerations
c. Transient dynamic events
d. Static or steady-state acceleration (0 Hz) due to charge leakage in piezoelectric materials
Correct Answer: d
Q) In an optical sensor like a photodiode, incident light is directly converted into:
a. Heat energy in the sensor junction
b. An electrical current (photocurrent) proportional to the light intensity
c. A change in capacitance of the device
d. Mechanical displacement of a diaphragm
Correct Answer: b
Q) A capacitive humidity sensor measures relative humidity by:
a. Using a heated wire to gauge moisture content
b. Detecting changes in capacitance caused by moisture altering the dielectric constant of a polymer between two electrodes
c. generating a voltage via a chemical reaction with water vapor
d. measuring the change in inductance of a coil exposed to humidity
Correct Answer: b
Q) A load cell (force/weight transducer) typically operates by:
a. Converting force into frequency changes of a vibrating element
b. Using bonded strain gauges in a Wheatstone bridge to convert applied force into a proportional electrical signal
c. Measuring displacement with an LVDT and correlating it to force
d. Sensing load via a change in inductance of a coil spring
Correct Answer: b
Q) A Hall effect sensor works on the principle that:
a. Resistance of a semiconductor sharply drops in a magnetic field
b. A magnetic field applied perpendicular to a current-carrying conductor produces a transverse voltage proportional to the field strength
c. Inductive coupling generates eddy currents in nearby metals
d. Magnetic domains in a material realign to produce a current
Correct Answer: b
Q) Inductive proximity sensors detect metal objects by:
a. Sensing changes in light reflectance from the object
b. Generating an AC magnetic field and detecting the impedance change due to eddy currents induced in the nearby conductive target
c. measuring the capacitance between the sensor and object
d. using a Hall effect element to sense magnetic properties of the metal
Correct Answer: b
Q) A MEMS vibrating-structure gyroscope senses angular rotation by:
a. Tracking the Earth’s magnetic field changes
b. Detecting Coriolis forces on a tiny vibrating mass, which cause a measurable deflection proportional to rotation rate
c. Measuring centrifugal force on a spinning disk
d. Using a pair of orthogonal accelerometers and integrating the output
Correct Answer: b
Q) Which statement differentiates a sensor from a transducer in instrumentation?
a. A sensor is a device that detects a physical quantity and converts it into an electrical signal, whereas a transducer is a broader term for any device that converts one form of energy to another (including sensors and actuators)
b. There is no real difference – the terms are interchangeable
c. A sensor outputs mechanical displacement, a transducer outputs electrical signals
d. Sensors are only analog while transducers are only digital
Correct Answer: a
Industrial Applications and Automation Sensors
Q) What is the primary benefit of using a Hall effect sensor for current measurement in high-power circuits?
a. It must be placed in series with the conductor
b. It only works for AC, not DC
c. It provides galvanic isolation (no direct electrical contact) while measuring magnetic field produced by current, allowing safe DC or AC current sensing
d. It does not require any calibration over time
Correct Answer: c
Q) Why are 4–20 mA current loops widely used for analog sensor signals in industrial automation?
a. They are cheaper than voltage signals
b. Current signals are less susceptible to noise and voltage drops over long distances, and the 4 mA “live zero” allows detection of wire breaks or faults
c. They can carry digital data on top without any extra modulation
d. They allow sensors to be powered with AC mains directly
Correct Answer: b
Q) Fiber-optic sensors are advantageous in industrial environments mainly because they:
a. Are the least expensive sensor type available
b. Have moving parts that amplify small signals
c. Are immune to electromagnetic interference (EMI) and can be used safely in high RF or high-voltage areas
d. Require no calibration at all over their lifetime
Correct Answer: c
Q) For non-contact level measurement of liquids in a tank, a commonly used sensor is:
a. A thermocouple with a long probe
b. A conductivity-based level switch
c. An ultrasonic level transmitter that uses time-of-flight of sound waves to determine the liquid level
d. A strain gauge bonded to the tank wall
Correct Answer: c
Q) Precise position feedback for an industrial robot or CNC machine axis is typically provided by:
a. A thermistor sensor
b. A pressure transducer
c. An optical rotary or linear encoder that generates digital pulses corresponding to movement
d. A bourdon tube mechanism
Correct Answer: c
Q) Most modern pressure transmitters measure process pressure by:
a. Sensing buoyancy changes
b. Measuring gas ionization current
c. Using a flexible diaphragm that deflects under pressure, with strain gauges (piezoresistors) or piezoelectric elements converting that deflection into an electrical signal
d. Counting rotations of a turbine in the flow
Correct Answer: c
Q) An electromagnetic flow meter (magnetic flowmeter) for conductive liquids operates based on:
a. Bernoulli’s principle (pressure difference)
b. Doppler shift of ultrasonic waves
c. Faraday’s law of electromagnetic induction – a voltage is induced proportional to flow velocity as the conductive fluid moves through a magnetic field
d. Thermal heating of the fluid and measuring temperature rise
Correct Answer: c
Q) A Coriolis mass flow meter measures the flow rate by:
a. Sensing a pressure drop across an orifice and applying Bernoulli’s equation
b. Detecting the twisting of vibrating flow tubes caused by the Coriolis forces of the moving mass, with the degree of tube deflection proportional to mass flow
c. Using a turbine and counting rotational speed
d. Timing ultrasonic pulses upstream and downstream
Correct Answer: b
Q) The standard method for pH measurement uses a glass electrode that:
a. Measures solution conductivity directly
b. Generates an electromotive force (voltage) across a thin glass membrane, proportional to the hydrogen ion concentration difference (pH) between inside and outside solutions
c. Uses a thermocouple sensing the solution temperature
d. Absorbs hydrogen ions and changes resistance linearly with pH
Correct Answer: b
Q) “Absolute” pressure, as opposed to gauge pressure, is pressure measured relative to:
a. The local atmospheric pressure
b. 1 atm at sea level
c. A reference pressure of 14.7 psi
d. A perfect vacuum (zero reference pressure)
Correct Answer: d
Q) Why do many strain-gauge load cells use a full Wheatstone bridge with four active gauges instead of a single gauge?
a. To reduce the number of wires needed
b. To increase sensitivity and automatically compensate for temperature and bending effects (pairs of gauges experience opposite strain, canceling common errors)
c. To allow the use of AC excitation instead of DC
d. To eliminate the need for calibration by the user
Correct Answer: b
Signal Conditioning and Interfacing in Sensors and Transducers
Q) What is the primary reason for using an instrumentation amplifier in sensor signal conditioning (e.g. for a Wheatstone bridge)?
a. To provide a high current drive to the sensor
b. To amplify very small differential sensor signals while rejecting common-mode noise or interference (high CMRR) for accurate low-level measurements
c. To convert a digital sensor output to analog
d. To oscillate the sensor at a certain frequency
Correct Answer: b
Q) A Wheatstone bridge is commonly used in sensor circuits (e.g. with strain gauges) to:
a. Convert a current signal to a frequency signal
b. linearize a nonlinear sensor’s output
c. Translate small changes in resistance (due to strain, pressure, etc.) into a measurable voltage imbalance, improving sensitivity and stability
d. provide isolation between sensor and measuring device
Correct Answer: c
Q) RTD temperature sensors often use 3-wire or 4-wire configurations in the field to:
a. Allow multiple sensors to be read with one device
b. Provide a redundant sensor in case one fails
c. Measure both temperature and pressure simultaneously
d. Cancel or compensate for the lead wire resistance error, improving measurement accuracy over long cable runs
Correct Answer: d
Q) For low-level analog signals (e.g. microvolt thermocouple signals or bridge outputs), the interconnecting cables should be:
a. As long as possible to improve reading
b. Run alongside power cables for convenience
c. Shielded and twisted pair, with proper grounding, to minimize pickup of electromagnetic noise and interference
d. Thin unshielded wires to reduce cost
Correct Answer: c
Q) According to the Nyquist–Shannon sampling theorem, to accurately digitize a sensor signal without aliasing, the sampling frequency should be:
a. At least twice the highest frequency component present in the sensor’s signal (the Nyquist rate)
b. Equal to the signal’s highest frequency
c. Half of the lowest frequency component
d. As high as possible regardless of signal bandwidth
Correct Answer: a
Q) In strain gauge measurements, using a full-bridge with four gauges (in tension/compression pairs) instead of a quarter-bridge (single gauge) will:
a. Eliminate the need for any amplification
b. Increase the output sensitivity and provide temperature compensation (as thermal effects cancel out) for more stable readings
c. Decrease the bridge output proportionally
d. Require a special amplifier since a standard one won’t work
Correct Answer: b
Calibration and Performance of Sensors and Transducers
Q) The hysteresis error of a sensor is due to:
a. Time delay between input change and output
b. Noise superimposed on the signal
c. Drift of the sensor zero over time
d. Different output values for the same input, depending on whether the input is increasing or decreasing (due to internal friction or material effects)
Correct Answer: d
Q) Which of the following can affect the accuracy of a sensor’s calibration?
a. Environmental conditions (temperature, humidity)
b. Mechanical stresses or vibrations
c. Electrical interference (EMI/RFI)
d. All of the above (multiple external factors can introduce errors if not accounted for)
Correct Answer: d
Q) “Accuracy” of an instrument is defined as:
a. Its ability to detect very small changes in input
b. The speed at which it responds to changes
c. The degree of closeness between the measured value and the true value
d. The consistency of output when the same input is applied repeatedly
Correct Answer: c
Q) “Drift” in a sensor or transducer refers to:
a. A sudden random change due to noise
b. The difference between increasing and decreasing readings
c. A time delay in the response to inputs
d. A slow change in the sensor’s output over time when the input is constant (zero or span output shifting gradually)
Correct Answer: d
Q) The linearity of a sensor’s transfer function indicates:
a. How quickly it responds to input changes
b. How closely the sensor’s output follows a straight-line relationship with the input across its range (minimal deviation from the ideal linear output)
c. The amount of random noise on the output
d. Its ability to return to zero after removing the input
Correct Answer: b
Q) In sensor specifications, “span” (full-scale span) is defined as:
a. The difference between the upper and lower measurement range limits of the sensor (full-scale output range)
b. The lowest value the sensor can detect
c. The time it takes for the sensor to stabilize
d. The output at the mid-scale point of the sensor
Correct Answer: a
Q) Resolution of a sensor or instrument refers to:
a. The smallest change in the input that produces a detectable change in output
b. The absolute accuracy at full scale
c. The slope of the input-output curve
d. The ratio of full-scale output to the noise level
Correct Answer: a
Q) Cold-junction compensation in thermocouple circuits is used to:
a. Linearize the thermocouple’s inherently nonlinear output
b. Protect the cold junction from overheating
c. Correct for the temperature of the reference junction (cold end) by adding a compensating voltage equal and opposite to the cold junction’s thermoelectric voltage, so the measurement reflects true hot-junction temperature
d. Average the readings of multiple thermocouples
Correct Answer: c
Q) Absolute pressure transducers must be calibrated against:
a. Atmospheric pressure as the zero reference
b. Another gauge sensor
c. Vacuum as the zero reference (since they measure pressure above absolute zero pressure)
d. An assumed sea-level standard pressure
Correct Answer: c
Smart Sensors and Recent Developments
Q) Which of the following best describes a “smart sensor”?
a. A sensor integrated with on-board microprocessor/processing, memory, and often communication interface, enabling it to perform signal conditioning, self-calibration, and data communication internally
b. Any sensor that provides an analog output signal
c. A sensor that does not require any power to operate
d. A sensor with 4–20 mA output instead of voltage output
Correct Answer: a
Q) Smart sensors typically convert their analog signals to digital internally. Which statement is true about smart sensor outputs?
a. They usually provide a digital output (or digitized data) after internal signal conditioning and A/D conversion, facilitating direct interface with microcontrollers or networks
b. They output higher-voltage analog signals (0–10 V) to reduce noise
c. They require external ADCs for digital interfacing
d. They only output in binary on/off format
Correct Answer: a
Q) IEEE 1451 is a set of standards that:
a. Define how to program PLCs for sensor input
b. Specify open network-independent interfaces for smart transducers, including the definition of a Transducer Electronic Data Sheet (TEDS) that stores sensor identification, calibration, and correction data
c. Describe safety requirements for electrical instruments
d. Outline the electromagnetic compatibility for sensors
Correct Answer: b
Q) In the context of smart sensing, a “soft sensor” (or virtual sensor) refers to:
a. A software algorithm that uses readings from multiple physical sensors and mathematical models to infer or estimate a process value that may be hard to measure directly
b. A sensor made of flexible (soft) materials
c. A sensor with damping to smooth its response
d. A sensor operating in a soft real-time network
Correct Answer: a
Q) MEMS (Micro-Electro-Mechanical Systems) sensors have become popular because they:
a. Are less accurate than macroscopic sensors but acceptable
b. Offer extremely small size and weight, low power consumption, and can be mass-produced with electronic integration for functions like acceleration, pressure, etc.
c. Do not require any calibration or temperature compensation
d. Work only at very high frequencies
Correct Answer: b
Q) The HART protocol (Highway Addressable Remote Transducer) is widely used in smart transmitters because it:
a. Is a purely wireless protocol for field sensors
b. Superimposes a low-level digital communication signal on the 4–20 mA analog loop, allowing bidirectional digital data exchange (device configuration, diagnostics, etc.) without disturbing the analog measurement
c. Uses high-voltage pulses on sensor lines for communication
d. Replaces the 4–20 mA signal entirely with a fieldbus
Correct Answer: b
Q) One major benefit of using smart sensors in an industrial control system is:
a. Higher power consumption to drive their intelligence
b. Built-in self-diagnostics and remote configurability, which reduce commissioning time and maintenance costs (e.g. easy calibration and health monitoring from the control room)
c. They make the control system completely maintenance-free
d. Elimination of all measurement errors without need for calibration
Correct Answer: b
Q) Wireless HART is best described as:
a. Wi-Fi adapted for sensor networks on industrial sites
b. A wireless extension of the HART protocol that enables smart field devices to form a mesh network for transmitting sensor data and diagnostics while remaining compatible with existing 4–20 mA systems
c. A Bluetooth profile for industrial sensors
d. A method for wireless power transmission to sensors
Correct Answer: b
Q) Absolute sensor calibration can be maintained in smart sensors by storing calibration curves or coefficients internally. In IEEE 1451-enabled “smart” transducers, this information is typically found in:
a. The PLC program memory
b. An on-board Transducer Electronic Data Sheet (TEDS), which contains the sensor’s unique calibration and identification data for plug-and-play integration
c. The analog output signal level
d. A cloud database accessed by the sensor in real-time
Correct Answer: b
I hope you like above blog. There is no cost associated in sharing the article in your social media. Thanks for reading!! Happy Learning!!
2 Comments
