Instrumentation and Control Standards: Introduction
In modern process industries, engineering decisions are rarely made in isolation. Every instrument tag, loop drawing, alarm configuration, or safety function is influenced by Instrumentation and Control Standards.
These standards exist to ensure safety, consistency, interoperability, and long-term reliability across industrial plants.
Standards are also one of the most misunderstood topics in instrumentation engineering. Engineers often face confusion when standards are mixed incorrectly, applied outside their scope, or oversimplified in technical discussions.
This article presents a sexplanation of Instrumentation and Control Standards, focusing on where each standard applies, why it exists, and how it should be used.
Disclaimer: This article provides an educational overview only. Standards are copyrighted documents. Always refer to the official and latest editions issued by the respective organizations for project execution.
What Are Instrumentation and Control Standards?
Instrumentation and Control Standards are formally published documents developed by recognized professional and international bodies to guide engineering practices in automation and process control. Their purpose is not to limit engineering creativity, but to provide a common technical language.
Well applied Instrumentation and Control Standards help engineers:
Design safer systems
Avoid ambiguity in drawings and documentation
Ensure compatibility between devices from different manufacturers
Meet regulatory, audit, and client requirements
Problems arise when standards are treated as general rules rather than scope specific guidance documents.
Why Standards Content Often Gets Criticized
Many engineers encounter negative feedback when discussing standards publicly. This usually happens due to:
Incorrect standard selection
A safety standard being referenced for PLC programming, or a communication standard being linked to alarm philosophy.Mixing standards with different scopes
For example, combining hazardous area standards with general signal wiring practices.Over-simplification
Many Instrumentation and Control Standards are published as series, not single documents.Ignoring industry context
Process industries, discrete manufacturing, and machinery safety follow different frameworks.
Understanding application context is essential to avoid these mistakes.
A Safer Way to Understand Standards: Activity-Based Classification
Instead of memorizing standard numbers, it is more practical to classify Instrumentation and Control Standards based on engineering activities.
1 Design and Documentation
Covers symbols, identification, P&IDs, loop diagrams, and engineering documents.
2 Field Instruments and Installation
Focuses on enclosure protection, hazardous area equipment, installation, inspection, and maintenance.
3 Control Systems and Automation
Includes PLCs, DCS, communication protocols, and device integration.
4 Functional Safety
Addresses risk reduction using Safety Instrumented Systems.
5 Alarms, HMI, and Human Factors
Ensures operator effectiveness, alarm usability, and ergonomic design.
This classification helps engineers apply Instrumentation and Control Standards correctly and consistently.
Core Instrumentation and Control Standards by Application
1 Ingress Protection and Environmental Suitability
IEC 60529 – IP Code
Defines the degree of protection provided by enclosures against solid objects and water. It is widely used when selecting field instruments, panels, and junction boxes for indoor or outdoor installations.
2 Control Valves and Final Control Elements
IEC 60534 Series – Industrial Process Control Valves
This multi-part standard covers terminology, sizing equations, testing methods, and performance characteristics of control valves. It is incorrect to treat it as a single “noise” or “cavitation” standard without identifying the applicable part.
3 PLC and Control System Programming
IEC 61131-3 – PLC Programming Languages
Defines programming concepts such as Ladder Diagram, Function Block Diagram, Structured Text, and Sequential Function Chart. It applies to PLC programming only and should not be confused with safety lifecycle standards.
4 Industrial Communication and Fieldbus Systems
IEC 61158 and IEC 61784
These standards address industrial communication networks and fieldbus profiles. They are used to ensure interoperability between automation devices and control systems.
IEC 61804 – EDDL (Electronic Device Description Language)
Used for device integration and configuration through electronic device descriptions.
IEC 62453 – FDT/DTM Concept
Defines the Field Device Tool (FDT) framework, allowing standardized access to intelligent field devices.
5 Hazardous Area and Explosion Protection
IEC 60079 Series – Explosive Atmospheres
This series covers equipment design, selection, installation, inspection, and maintenance in hazardous areas. Different parts address different lifecycle stages and protection concepts.
Hazardous area standards should always be treated separately from general instrumentation wiring practices.
6 Analog Signals and Device Diagnostics
NAMUR NE 43
Defines standardized fault signal ranges for 4–20 mA analog signals, enabling control systems to detect device failures reliably.
NAMUR NE 107
Standardizes diagnostic status signals from intelligent field devices, improving alarm clarity and reducing operator overload.
7 Instrumentation Symbols and Documentation
ISA-5.1 – Instrumentation Symbols and Identification
Defines symbols and identification methods used in P&IDs and drawings. It ensures that engineering documents are readable and consistent across organizations.
8 Functional Safety and Safety Instrumented Systems
IEC 61511 – Safety Instrumented Systems (Process Industry)
One of the most critical Instrumentation and Control Standards, IEC 61511 defines requirements for the entire SIS lifecycle, from risk assessment and specification to operation and maintenance.
It is a functional safety standard, not a PLC programming guide.
9 Alarm Management and Operator Awareness
IEC 62682 – Alarm Management
Provides alarm management principles and lifecycle requirements for process industries.
ISA-18.2 – Alarm Management
Widely recognized and closely aligned with IEC 62682, focusing on alarm philosophy, rationalization, performance metrics, and continuous improvement.
EEMUA 191 – Alarm Systems Guidance
A highly respected guide that complements international alarm management standards and is widely referenced by EPCs and end users.
10 Human-Machine Interface and Ergonomics
ISA-101 – HMI for Process Automation
Defines a lifecycle approach to HMI design, emphasizing usability, consistency, and operator effectiveness rather than aesthetics alone.
ISO 11064 – Ergonomic Design of Control Centres
Addresses control room layout, workstation design, and human factors to reduce operator fatigue and errors.
Common Mistakes Engineers Make with Standards
Assuming one standard fits all industries
Using incorrect standard numbers
Mixing safety, control, and documentation standards
Ignoring client-specific engineering specifications
Treating Instrumentation and Control Standards as shortcuts
These mistakes are the main reasons standards-related content is challenged publicly.
Best Practices for Using Instrumentation and Control Standards
Clearly define the engineering activity
Confirm the standard’s scope and industry relevance
Use standards as guidance, not substitutes for engineering judgment
Align with client and regulatory requirements
Refer to the latest published edition
Why Standards Matter to Clients and End Users
For clients, Instrumentation and Control Standards deliver:
Improved safety
Predictable system behavior
Easier maintenance and troubleshooting
Faster audits and approvals
Long-term plant reliability
Engineers who understand standards properly build trust and professional credibility.
What we learn today?
Instrumentation and Control Standards are essential tools for modern automation engineering. The real challenge is not memorizing standard numbers, but understanding where and how each standard applies.
By adopting a structured, activity-based approach, engineers can apply standards correctly, avoid misinformation, and design systems that meet both technical and client expectations.
When used responsibly, Instrumentation and Control Standards become a foundation for safe, reliable, and efficient industrial operations.
References – Instrumentation & Control Standards
| No. | Standard / Organization | Website Link |
|---|---|---|
| 1 | International Electrotechnical Commission (IEC) | https://www.iec.ch |
| 2 | IEC 60529 – IP Code | https://www.iec.ch |
| 3 | IEC 60534 – Control Valves (Series) | https://www.iec.ch |
| 4 | IEC 61131-3 – PLC Programming Languages | https://www.iec.ch |
| 5 | IEC 61158 – Industrial Communication Networks | https://www.iec.ch |
| 6 | IEC 61784 – Fieldbus Profiles | https://www.iec.ch |
| 7 | IEC 60079 – Explosive Atmospheres | https://www.iec.ch |
| 8 | IEC 61511 – Safety Instrumented Systems | https://www.iec.ch |
| 9 | IEC 62682 – Alarm Management | https://www.iec.ch |
| 10 | International Society of Automation (ISA) | https://www.isa.org |
| 11 | ISA-5.1 – Instrumentation Symbols | https://www.isa.org/standards |
| 12 | ISA-18.2 – Alarm Management | https://www.isa.org/standards |
| 13 | ISA-101 – Human-Machine Interface | https://www.isa.org/standards |
| 14 | NAMUR NE 43 & NE 107 | https://www.namur.net |
| 15 | EEMUA Publication 191 | https://www.eemua.org |
| 16 | ISO 11064 – Control Centre Ergonomics | https://www.iso.org |
